Specification |
|
|
Panel Material |
ABS Panel |
|
Dimensions |
92Lx56Wx23H(mm) |
|
Voltage |
DC9-12V |
| Working Current | ＜600mA |
|
Output |
NO+NC+COM |
|
Mechanical Life |
1000000 tested |
|
Operating Temp |
-30℃ ~ 60°C |
|
Operating Humidity |
20%-80% (non- condensing) |
|
Suitable for Door |
Hollow Door |
| Tuya(WiFi function) | Remote unlock with mobile phone |
|
Led indicator |
|
|
White LED indicator |
Power OFF |
|
Blue LED indicator |
Power ON(standby) |
|
Green LED indicator |
Power ON(sensation) |
